When the palmrest assembly removed you can access the following internal components: Lift up and remove the palmrest assembly. Separate the palmrest assembly from the bottom case with a piece of soft plastic. Remove four screw securing the palmrest assembly. Pull DVD drive to the left and remove it. Remove one screw securing the optical DVD drive. It means you can install up to 4GB RAM module into each slot. You’ll find both memory modules under the cover.įor the purpose of my guide it’s not necessary to remove memory modules.īy the way, Dell Inspiron 17R N7110 uses PC3-10666 DDR3-1333 204pin SDRAM SODIMM memory.
Remove one screw securing the memory cover on the bottom. Now you can pull the cable from the connector. On this picture the same connector shown in the unlocked position. The tap will open up at a 90 degree angle. Lift up the left side of the brown tab with your fingernail.
On this picture the keyboard connector shown in the locked position. In the following two steps I explain how to unlock the connector and release the cable. Now you can access the keyboard cable which is connected to the motherboard. Finally, lift up the top side of the keyboard and place the keyboard upside down on the palmrest.
